Fitment: Our this 4-Stroke Motor Short Case Engine only compatible with 150cc engine size two-wheeled scooters(Not suitable for go kart).
Widely used in all kinds of two-wheeled scooter;without reverse gear, continuously variable.
Transmission CVT: CVT consist mainly of 2 transmission pulleys and 2 transmission belts; It??s compact, simple design offers seamless shifting between an unlimited amount of varying gear ratios, allowing a smooth rate of acceleration
This complete engine set includes carburetor, CDI, starter solenoid, coil,kick start lever.
Without reverse gear, long axle, short box, it can be installed on the ATV, but you need to install an additional reverse gear. Product Description
Specification:
Model number: ??IP570QMJ
Weight:28.18kg/62.13lb
Engine oil type: SF15W-40 not come with oil.
Cooling: air cooled
Displacement: 150cc
Short case
Engine type: GY6 single cylinder 4-stroke
Max power(kw/r/min): 6kw/7500r/min
Rated power(kw/r/min): 5.2kw/7000r/min
Max torque(n.m/r/min):7.6N.m/6500r/min
Min specific fuel consumption: 367g/kw.h, allow add 10%
Minimum no-load steady speed:1700+-170r/min
Piston diameter:57.4mm/2.06″
Piston stroke: 57.8mm/2.28″
Cylinder volume:149.5ml
Compression ratio: 9.2:1
Ignition system: CDI
Transmission: CVT
Start method: electric/kick
Fuel Oil
a) Gasoline trademark: Above RQ90
b) Engine oil trademark: crank shaft box SAE15W-40. Gearbox SAE90
c) Total volume for Engine oil: more than 0.9L for crank shaft box; more than 0.1L gear box
Package included:
1x Set of complete engine
Notice:
Add engine oil before use??This machine is 10″ short case??
Mounting holes are located at the above of machine !
