Brand New 49cc Air Cooled Complete Gasoline Scooter Engine Throttle Cable and Grip Kit with Red CNC Racing Intake Manifold High Flow Air Fileter
The engine with built-in square exhaust muffler, centrifugal clutch and gearbox
The kit comes with 3 pieces of output sprockets (14,17 and 20 teeth )fit T8F BF05T 8mm pitch chains. Offers you more ratio and speed choices
Kit Includes: 1 x 49cc engine with racing air filter, 1 x Throttle Cable , 1 x Throttle Clamp with Kill Switch, 1 x Left Grip , 1 x Right Grip, 1 x 14t sprocket, 1 x 17t sprocket,1 x 20t sprocket
Fit Majority of gas scooters, some pocket bikes, and mini choppers, Mini Quad Kid ATV. Always wanted to finish that project but couldn’t find a small compact, but powerful motor? Your gas scooter engine has blown/passed on but you don’t want to spend hundreds on rebuilding or buying a brand new bike? Wanting to upgrade that slow and old 43cc engine to a new and larger capacity 49cc engine to blow away the competition?Want to beat the bidding rush and have this engine in your hands as soon as possible? Then this engine is what you need! Specifications: 49cc single cylinder, air-cooled, 2-stroke gasoline scooter engine
Fuel: 25:1 gasoline / engine oil mix
Displacement:49cc
Gear Box Reduction Rate: 3.55 : 1 (with 20t sprocket)
Output Sprocket Rotation: Anti-clock (when you face the gear box)
Start Way: pull start
Cooling: Air forced cooling
Sprocket Size: 14,17 and 20 teeth fit T8F BF05T 8mm pitch chains
Spark Plug Size: BM6A
Max Power: 1.5kw/7000rpm
Bottom Mounting Brackets: 3-7/8 Inch or 98mm
Top Through Hole Diameter M.B.: 0.161 Inch
Bottom Through Hole Diameter M.B.: 0.245 Inch
Exhaust Diameter: 0.589 Inch
Connector: 2 Pin
Length: 11-13/16 Inch or 30cm
Width: 12-3/16 Inch or 31cm
Height: 7-7/8 Inch or 20cm
Clutch Mounting Hole Distance: 2-7/8 Inch or 73mm
Clutch Mounting Hole Diameter: 5/16 Inch
Clutch Pad: 2 Shoe
Carburetor Hole Diameter: 0.213″
Pull Start Mounting Hole Distance:2-7/8 Inch or 73mm
Weight: 4.5KG
