Made of high material for durability and stability

Pressure can be adjusted by springs or air (nitrogen); Operation of the coil-over springs and air cylinder is helpful to reduce the shock

No instruction included, professional installation recommended

The suspension leg provides a smoother ride and better shock absorption management. The spring seat is insulated from the spring to ensure a quiet and comfortable ride

The suspension shocks struts provides a smoother ride and better overall damping management
Color:320mm Gray
Specifications:
Length of Eye to Clevis Eye Total Length Spring Thickness Spring Width WorStroke Maximum load
280mm (11″) 350mm (13 3/4″) 7mm 60mm 60mm 150kg (??330 lbs)
320mm (12 5/8″) 350mm (13 3/4″) 7mm 60mm 60mm 200 kg (??440 lbs)
Clevis Hole Diameter: 8mm
Clevis Inner Width: 20mm
Clevis Maximum Tensile Strength: 2,000 Kgf
Spring Stiffness: 110 kg
Air Reservoir: Adjustable
Factory Air Pressure: 0.4 Mpa
Maximum Air Pressure: 0.5 Mpa
Fitting manual is not included. installed by qualified mechanic is recommended.Package included: 1 pcs Shock Absorbers
Note:
This product is measured by hand and may have an error of 1-3cm, which is based on the actual product.
If you have any questions, please feel free to email!
This type of motorcycle shock absorber is designed to reduce the vibration caused by rough roads.
