SKU DHXQ.01565 G07-1561 Category Tags , , , ,

Description

11 coil magneto stator for use on 125cc GY6 152QMI and 150cc GY6 157QMJ gas scooter engines. Also sometimes referred to as a stator comp.
This stator comes equipped with a 4+2 wiring connector.
This stator may be compatible with 150cc ATVs dirt bikes. Please check images to verify. Specifications

Diameter: 88 mm (3-1/2″)
Width: 30 mm (1-3/16″)
Center Hole Diameter: 29 mm (1-3/16″)
Bolt Hole Spacing: 40 mm (1-9/16″)
Bolt Hole Diameter: 6 mm (1/4″)
Coil Wire Length: 580 mm (23″)
Number of Coils: 11
Connector: 4 pin connector, plus 2 single pins
